BRAND & MODEL

SPECIFICATION

UNITS

Fanuc Robocut
Model : Alpha 1ic (Submerged Type)

Max. Workpiece Dimensions : 820 x 730 x 180mm
Max. Workpiece Weight : 1,000 Kg
Axis Travel Range : 550(X) x 370(Y) x 310(Z)
Wire Diameter : 0.1mm , 0.2mm , 0.25mm

1

Mitsubishi BA Series
Model : BA 24 (Submerged Type)

Max. Workpiece dimensions : 1050(w) x 820 (D) x 305 (H) mm
Max. Workpiece Weight : 1500 Kg
Axis Travel Range : 600(x) x 400(Y) x 310(Z)
Wire Diameter : 0.1mm , 0.2mm , 0.25mm

1

Seibu High Precision Wire Cut
Model : M 50 A (Submerged Type)

Max. Workpiece dimensions : 800(w) x 650 (D) x 300 (H) mm
Max. Workpiece Weight : 800 Kg
Axis Travel Range : 500(x) x 350(Y) x 310(Z)
Wire Diameter : 0.1mm , 0.2mm , 0.25mm

1

Seibu High Precision Wire Cut
Model : M 500 S (Submerged Type)

Max. Workpiece dimensions : 800(w) x 650 (D) x 300 (H) mm
Max. Workpiece Weight : 800 Kg
Axis Travel Range : 500(x) x 350(Y) x 310(Z)
Wire Diameter : 0.1mm , 0.2mm , 0.25mm

1

Seibu High Precision Wire Cut
Model : M 750 B (Submerged Type)

Max. Workpiece dimensions : 1000(W) x 750 (D) x 300 (H) mm

Max. Workpiece Weight : 800 Kg

Axis Travel Range : 750 (x) x 500 (Y) x 310(Z)

Wire Diameter : 0.1mm , 0.2mm , 0.25mm

1

Seibu High Precision Wire Cut

Model : M 35 HP

Max. Workpiece dimensions : 700(W) x 630 (D) x 220 (H) mm

Max. Workpiece Weight : 350 Kg

Axis Travel Range : 350 (x) x 300 (Y) x 230(Z)

1

Sundor Laser Marking Machine

Marking area
110 x 110mm, 175 x 175mm, 220 x 220mm, 300 x 300mm, 500 x 500mm
Laser repetition frequency : 20KHZ-80KHZ
Marking speed : 7000-12000mm/s

1

Quality Control Facilities

Vision Measurement Machine

WVISION 2.5D

Model : WV5040C

Measuring Range : 500mm x 400mm

Caliper

Micro Meter

High Gauge

Pin Gauge Set

Block Gauge Set

1

Ocean ZNC Super Drill
Model : OCT-3020 ZA

Copper Tube Diameter : 0.1 / 0.3 / 0.5 / 0.8 / 2.0 / 2.5 / 3.0 (mm)

1

Profile Projector

Horizontal Profile Projector, an ergonomic measuring instrument with reliable mechanical structure and high precision magnification, can effectively and efficiently inspect profile, section, surface and outline of complicated workpiece

1
